Description

Cisco Barebone System – 2U Rack-mountable – 2 x Processor Support

The UCS C245 M6 SFF server extends the capabilities of Cisco’s Unified Computing System portfolio in a 2U form factor with the addition of the AMD CPUs, 16 DIMM slots per CPU for 3200-MHz DDR4 DIMMs with individual DIMM capacity points up to 256 GB. The maximum memory capacity for 2 CPUs is 8 TB (for 32 x 256 GB DDR4 DIMMs). The C245 M6 SFF server has:

• Up to 24 front SFF SAS/SATA HDDs or SSDs (optionally up to 4 of the drives can be NVMe)
• I/O-centric option provides up to 8 PCie slots using three rear risers, or
• Storage-centric option provides three rear risers with a total of up to 4 NVMe SFF drives and 3 PCIe slots

The server provides internal slots for the following:

• One Cisco 12G SAS RAID controllers with 4 GB cache backup to control SAS/SATA drives, or
• Cisco 12G SAS HBAs to control SAS/SATA drives

The UCS C245 M6 server has a single 1 GbE management port. A modular LAN on motherboard (mLOM)/OCP 3.0 module provides up to two 100 GbE ports. A connector on the front of the chassis provides KVM functionality.

The Cisco UCS C245 M6 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.

• Perform computational tasks effectively accrediting the EPYC processor
• DDR4 SDRAM compatible slot – Install memory that synchronizes electrical and clock signals for an efficient data throughput
• Gigabit Ethernet enables higher aggregate data transfer capacity which results in a better overall performance
• Connect USB-enabled devices via 2 USB ports
• 12Gb/s SAS interface for high speed and reliability
